Cpu Specifications

Total Cores: 16

• Of Performance-cores: 8
• Of Efficient-cores: 8
• Total Threads: 24
• Max Turbo Frequency: 5.40 Ghz
• Intel® Turbo Boost Max Technology 3.0 Frequency !: 5.40 Ghz
• Performance-core Max Turbo Frequency: 5.30 Ghz
• Efficient-core Max Turbo Frequency: 4.20 Ghz
• Performance-core Base Frequency: 3.40 Ghz
• Efficient-core Base Frequency: 2.50 Ghz
• Cache: 30 Mb Intel® Smart Cache
• Total L2 Cache: 24 Mb
• Processor Base Power: 125 W
• Maximum Turbo Power: 253 W

Memory Specifications

Max Memory Size (dependent On Memory Type): 128 Gb

• Memory Types:
• Up To Ddr5 5600 Mt/s
• Up To Ddr4 3200 Mt/s
• Max Of Memory Channels: 2
• Max Memory Bandwidth: 89.6 Gb/s

Processor Graphics

Processor Graphics !: Intel® Uhd Graphics 770

• Graphics Base Frequency: 300 Mhz
• Graphics Max Dynamic Frequency: 1.60 Ghz
• Graphics Output: Edp 1.4b, Dp 1.4a, Hdmi 2.1
• Execution Units: 32
• Max Resolution (hdmi)!: 4096 X 2160 @ 60hz
• Max Resolution (dp)!: 7680 X 4320 @ 60hz
• Max Resolution (edp - Integrated Flat Panel)!: 5120 X 3200 @ 120hz
• Directx* Support: 12
• Opengl* Support: 4.5
• Opencl* Support: 3.0
• Multi-format Codec Engines: 2
• Intel® Quick Sync Video: Yes
• Intel® Clear Video Hd Technology: Yes
• Of Displays Supported !: 4
• Device Id: 0xa780

Expansion Options

Direct Media Interface (dmi) Revision: 4.0

• Max Of Dmi Lanes: 8
• Scalability: 1s Only
• Pci Express Revision: 5.0 And 4.0
• Pci Express Configurations !: Up To 1x16+4, 2x8+4
• Max Of Pci Express Lanes: 20

Package Specifications

Sockets Supported: Fclga1700

• Max Cpu Configuration: 1
• Tjunction: 100°c

Advanced Technologies

Intel® Gaussian & Neural Accelerator: 3.0

• Intel® Thread Director: Yes
• Intel® Deep Learning Boost (intel® Dl Boost): Yes
• Intel® Speed Shift Technology: Yes
• Intel® Turbo Boost Max Technology 3.0 !: Yes
• Intel® Turbo Boost Technology !: 2.0
• Intel® Hyper-threading Technology !: Yes
• Intel® 64 !: Yes
• Instruction Set: 64-bit
• Instruction Set Extensions: Intel® Sse4.1, Intel® Sse4.2, Intel® Avx2
• Idle States: Yes
• Enhanced Intel Speedstep® Technology: Yes
• Thermal Monitoring Technologies: Yes
• Intel® Volume Management Device (vmd): Yes

Security & Reliability

Intel® Standard Manageability (ism) !: Yes

• Intel® Control-flow Enforcement Technology: Yes
• Intel® Aes New Instructions: Yes
• Secure Key: Yes
• Intel® Os Guard: Yes
• Execute Disable Bit !: Yes
• Intel® Boot Guard: Yes
• Mode-based Execute Control (mbec): Yes
• Intel® Virtualization Technology (vt-x) !: Yes
• Intel® Virtualization Technology For Directed I/o (vt-d) !: Yes
• Intel® Vt-x With Extended Page Tables (ept) !: Yes

Garantía

• Tres Años
