Cpu

• Amd Am4 Socket Amd Ryzen- 2nd Generation/ryzen- With Radeon- Vega Graphics/ryzen- 1st Generation Processors
• Supports Cpu Up To 8 Cores
• * Refer To Www.asus.com For Cpu Support List

Chipset

• Amd B450

Memoria

• Amd Ryzen- 2nd Generation/ Ryzen- With Radeon- Vega Graphics/ Ryzen- 1st Generation Processors
• 4 X Dimm, Max. 64gb, Ddr4 3200(o.c.)/3000(o.c.)/2800(o.c.)/2666/2400/2133 Mhz Un-buffered Memory
• Dual Channel Memory Architecture
• Ecc Memory (ecc Mode) Support Varies By Cpu.
• * Refer To Www.asus.com For The Memory Qvl (qualified Vendors Lists).

Gráfica

• Integrated In The Amd Ryzen- With Radeon- Vega Graphics Processors
• Multi-vga Output Support : Hdmi/dvi-d Ports
• - Supports Hdmi 2.0b With Maximum Resolution Of 4096 X 2160 @ 60 Hz
• - Supports Dvi-d With Max. Resolution 1920 X 1200 @ 60 Hz

Compatible Multi-gpu

• Supports Amd Crossfirex- Technology

Ranuras De Expansión

• Amd Ryzen- 2nd Generation/ Ryzen- 1st Generation Processors
• 1 X Pcie 3.0/2.0 X16 (x16 Mode)
• Amd Ryzen- With Radeon- Vega Graphics Processor
• 1 X Pcie 3.0/2.0 X16 (x8 Mode)
• Amd B450 Chipset
• 1 X Pcie 2.0 X16 (max At X4 Mode)
• 3 X Pcie 2.0 X1

Almacenamiento

• Amd Ryzen- 2nd Generation/ Ryzen- With Radeon- Vega Graphics/ Ryzen- 1st Generation Processors :
• 1 X M.2 Socket 3, With M Key, Type 2242/2260/2280/22110 Storage Devices Support (sata & Pcie 3.0 X 4 Mode)*1
• 2 X Sata 6gb/s Port(s)
• Amd B450 Chipset :
• 4 X Sata 6gb/s Port(s)
• Support Raid 0, 1, 10

Red

• Realtek® Rtl8111h
• Asus Lan Guard

Audio

• Realtek® Alc887-vd2 8-channel High Definition Audio Codec *2
• Audio Feature :
• - Led-illuminated Design - Brighten Up Your Build With The Gorgeous Illuminated Audio Trace Path.
• - Audio Shielding: Ensures Precision Analog/digital Separation And Greatly Reduced Multi-lateral Interference
• - Dedicated Audio Pcb Layers: Separate Layers For Left And Right Channels To Guard The Quality Of The Sensitive Audio Signals
• - Premium Japanese Audio Capacitors: Provide Warm, Natural And Immersive Sound With Exceptional Clarity And Fidelity

Puertos Usb

• Amd Ryzen- 2nd Generation/ Ryzen- With Radeon- Vega Graphics/ Ryzen- 1st Generation :
• 2 X Usb 3.1 Gen 1 Port(s) (2 At Back Panel, , Type-a)
• Amd Ryzen- 2nd Generation/ Ryzen- With Radeon- Vega Graphics/ Ryzen- 1st Generation :
• 1 X Usb 3.1 Gen 1 Port(s) (1 At Back Panel, , Usb Type-ctm)
• Amd B450 Chipset :
• 2 X Usb 3.1 Gen 2 Port(s) (2 At Back Panel, , Type-a)
• Amd B450 Chipset :
• 2 X Usb 3.1 Gen 1 Port(s) (2 At Mid-board)
• Amd B450 Chipset :
• 6 X Usb 2.0 Port(s) (2 At Back Panel, , 4 At Mid-board)

Características Especiales

• Asus Tuf Protection
• - Asus Safeslot Core: Fortified Pcie With Solid Soldering
• - Asus Esd Guard: Enhanced Esd Protection
• - Asus Overvoltage Protection: World-class Circuit-protecting Power Design
• - Asus Stainless-steel Back I/o: 3x Corrosion-resistance For Greater Durability!
• - Asus Digi+ Vrm: 6 Phase Digital Power Design
• Asus Exclusive Features :
• - Ai Suite 3
• - Ai Charger
• - Pc Cleaner
• - File Transfer
• Asus Quiet Thermal Solution :
• - Stylish Fanless Design Heat-sink Solution & Mos Heatsink
• - Asus Fan Xpert 4 Core
• Asus Ez Diy :
• - Asus Crashfree Bios 3
• - Asus Ez Flash 3
• - Asus Uefi Bios Ez Mode
• Asus Q-design :
• - Asus Q-slot
• - Asus Q-dimm
• Overclocking Protection :
• - Asus C.p.r.(cpu Parameter Recall)

E/s Panel Trasero

• 1 X Ps/2 Keyboard/mouse Combo Port(s)
• 1 X Dvi-d
• 1 X Hdmi
• 1 X Lan (rj45) Port(s)
• 1 X 5gb/s Port(s) Usb Type-ctm
• 2 X Usb 3.1 Gen 2 (teal Blue)type-a,
• 2 X Usb 3.1 Gen 1 (blue) Type-a,
• 2 X Usb 2.0
• 3 X Audio Jack(s)

E/s Internas

• 1 X Aura Rgb Strip Header
• 1 X Usb 3.1 Gen 1(up To 5gbps) Connector(s) Support(s) Additional 2 Usb 3.1 Gen 1 Port(s) (19-pin)
• 2 X Usb 2.0 Connector(s) Support(s) Additional 4 Usb 2.0 Port(s)
• 1 X M.2 Socket 3 With M Key, Type 2242/2260/2280/22110 Storage Devices Support (sata & Pcie 3.0 X 4 Mode)
• 6 X Sata 6gb/s Connector(s)
• 1 X Cpu Fan Connector(s) (1 X 4 -pin)
• 3 X Chassis Fan Connector(s) (3 X 4 -pin)
• 1 X Aio_pump Connector (1 X 4 -pin)
• 1 X S/pdif Out Header(s)
• 1 X 24-pin Eatx Power Connector(s)
• 1 X 8-pin Atx 12v Power Connector(s)
• 1 X Front Panel Audio Connector(s) (aafp)
• 1 X System Panel(s)
• 1 X Clear Cmos Jumper(s)
• 1 X Com Port Header

Accesorios

• User´s Manual
• I/o Shield
• 2 X Sata 6gb/s Cable(s)
• 1 X M.2 Screw Package
• 1 X Supporting Dvd

Bios

• 128 Mb Flash Rom, Uefi Ami Bios, Pnp, Sm Bios 3.1, Acpi 6.1, Multi-language Bios, Asus Ez Flash 3, Asus Crashfree Bios 3, F3 My Favorite, Last Modified Log, F12 Printscreen,f4 Aura On/off, F9 Search And Asus Dram Spd (serial Presence Detect) Memory Information

Capacidad De Gestión

• Wol By Pme, Pxe

Sistema Operativo

• Windows® 10 64-bit

Factor De Forma

• Atx Form Factor
• 12.0 Inch X 9.2 Inch ( 30.5 Cm X 23.4 Cm )

Garantía

• Tres Años
